Flexible Film Pressure Sensor Detection Module MY2801
Multiple Display Modes
Real-Time Pressure Detection
Calibration Function
Multi-Language Display
Low Power Consumption
Large Data Storage
The feature-packed MY2801 flexible sensor detection technology comes with a 2.5-inch multi-language display (English & Chinese) and boasts a high-resolution 28,000 pixel monochrome dot matrix screen. Powered by a 3.7V rechargeable lithium battery (1200mAh), it offers convenient charging and data exchange via the Micro USB interface (DC 5V).
With a power consumption of 30mA, it ensures energy efficiency.. Experience convenience and functionality in one compact package.
Flexible Film Pressure Sensor Detection Module MY2801
The MY2801 multi-functional module is specifically designed for the measurement and calibration of flexible membrane pressure sensors, offering exceptional accuracy and reliability.
Operating with a rechargeable lithium ion battery, this device integrates various components including sensor signal processing, data transmission, main control, storage, display, and more. It provides real-time pressure detection and display, and can store your collected data within a large internal memory.
Data storage is made effortless with the module’s generous capacity, allowing for the storage of up to 2000 records. If you need to set parameters, the MY2801 has interactive functions and touch buttons that enable users to easily read data and configure parameters as needed. For example, the pressure display unit can be easily switched between Kg/g and N, allowing for seamless integration into various applications.
Additionally, it offers a pressure sensor calibration function where you can configure compatible flexible pressure sensors and ensures highly accurate pressure detection, guaranteeing precise measurements.
With multiple display modes on the main interface, users can conveniently view pressure values, pressure changes, and AD values in real-time.
Other highlights:
The MY2801 module boasts additional features such as the Peak Hold function, which captures and displays peak pressure values, and a real-time clock, providing users with the convenience of displaying the current time.
